Hydraulic Control Valve | Irrigation Control Valves | IR-105-54-X

Hydraulic Control Valve Irrigation Control Valves | IR-105-54-X

The BERMAD Normally Closed Control Valve with Hydraulic Control is a hydraulically operated, diaphragm actuated control valve, which opens in response to a remote pressure rise command and shuts in the absence of that command.

  • Hydraulically Controlled, Normally Closed Valve

-Line pressure driven

-Closes upon control failure

-Amplifies and relays weak remote command

  • Engineered Plastic Valve with Industrial Grade Design

-Highly durable, chemical and cavitation resistant

-No internal bolts and nuts

  • hYflow ‘Y’ Valve Body with “Look Through” Design

-Ultra-high flow capacity – Low pressure loss

  • Unitized Flexible Super Travel (FST) Diaphragm and Guided Plug

-Smooth closing

-Requires low opening and actuation pressure

-Prevents diaphragm erosion and distortion

  • Simple In-Line Inspection and Service.

Typical Applications

  •  Computerized Irrigation Systems
  • Remote/Elevated Systems
  • Distribution Centers
  • Low Supplied Pressure Irrigation Systems
  • Energy Saving Irrigation Systems





[1] BERMAD Model IR-105-54-X opens upon pressure rise command.

[2] BERMAD Relief Valve Model IR-13Q.

[3] BERMAD Air Valve Model ARA-A-P-P.

[4] BERMAD Vacuum Breaker Model 1/2″- ARV.
